iCare EIDON Family
TrueColor confocal fundus cameras with widefield imaging, autofluorescence, and fluorescein angiography — all non-mydriatic and fully automated.
Explore the EIDON family
See the equipment and manufacturer examples up close. Select an image to enlarge it, then bring your workflow questions to a demonstration.
EIDON TrueColor retinal example
White-light confocal retinal imaging available across the EIDON family.
EIDON infrared retinal example
Infrared imaging complements the TrueColor view across the EIDON family.
EIDON autofluorescence example
Blue autofluorescence is available on EIDON AF and EIDON FA configurations.
EIDON fluorescein angiography example
Fluorescein angiography requires the EIDON FA model and contrast administration; it is not a base EIDON feature.
TrueColor Confocal Technology
Unlike conventional fundus cameras that use flash illumination, the EIDON family uses white LED confocal scanning to produce TrueColor images with consistent color reproduction, sharp detail, and reduced artifacts — even through small pupils and media opacities.
Confocal Optics
Sharper images with reduced scatter and improved contrast
Non-Mydriatic
Minimum 2.5 mm pupil — no dilation required
Fully Automated
Auto-align, auto-focus, auto-exposure, auto-capture
Widefield
90° single capture, up to 200° mosaic with UWF
Three Models, One Platform
Choose the EIDON configuration that fits your practice's diagnostic needs — from essential fundus imaging to a complete angiography suite.
iCare EIDON
TrueColor confocal fundus camera with widefield capability. The foundation of the EIDON family.
- TrueColor confocal imaging with white LED illumination
- Infrared (IR) imaging
- Red-free and RGB channel separation
- 90° single capture, up to 160° mosaic (200° with UWF module)
- Non-mydriatic — minimum 2.5 mm pupil
iCare EIDON AF
Adds blue autofluorescence (FAF) imaging to the EIDON platform for enhanced retinal visualization.
- All EIDON imaging modalities included
- Blue autofluorescence (FAF) imaging
- Blue LED excitation (440–475 nm)
- Panoramic FAF mosaics up to 160°
- Non-mydriatic — minimum 2.5 mm pupil
iCare EIDON FA
The complete EIDON platform with fluorescein angiography and video capture for comprehensive vascular imaging.
- All EIDON and EIDON AF imaging modalities
- Fluorescein angiography (FA) with video
- FA video resolution: 1840 × 1644 at 5 fps
- 2 TB SSD storage (vs 480 GB on other models)
- Complete imaging suite in one device
Imaging Modality Comparison
| Modality | EIDON | EIDON AF | EIDON FA |
|---|---|---|---|
| TrueColor Confocal | |||
| Infrared (IR) | |||
| Red-Free / RGB Channels | |||
| Blue Autofluorescence (FAF) | — | ||
| Fluorescein Angiography (FA) | — | — | |
| FA Video Capture | — | — |
Technical Specifications
Shared Across All Models
| Sensor Resolution | 14 Mpixel (4608 × 3288) |
| Field of View (single capture) | 90° |
| Mosaic Field of View | Up to 160° (200° with UWF module) |
| Minimum Pupil Size | 2.5 mm (non-mydriatic) |
| Automation | Auto-align, auto-focus, auto-exposure, auto-capture |
| Operation | Tablet-operated, all-in-one design |
| Dimensions | 360 × 590 × 620 mm |
| Weight | 25 kg |
Model-Specific Differences
| Spec | EIDON | EIDON AF | EIDON FA |
|---|---|---|---|
| Storage | 480 GB SSD | 480 GB SSD | 2 TB SSD |
| Light Sources | White + IR LEDs | White + IR + Blue LEDs | White + IR + Blue + FA LEDs |
| FA Video Resolution | — | — | 1840 × 1644 @ 5 fps |
